TCC-1400
Base Rating | 140 Ton @ 10'( 127 Mt @ 2.3 m |
---|---|
Main Boom | Six Section Formed Boom Six Section Formed Boom |
Length (min-max) | 42.3 - 195.3 ft 12.9 - 59.5 m |
Telescope System | Pin & Latch Pin & Latch |
Attachment - Option 3 | 10 - 31 - 55 ft Stowable, 3-Piece bi-fold lattice fly 3.0 - 9.4 - 16.7 m Stowable, 3-Piece bi-fold lattice fly |
Maximum Tip Height | 257.6 ft 78.5 m |
Engine Make & Model | Cummins QSL 9L Cummins QSL 9L |
Horsepower | 320 hp (239kW) @ 1,800 rpm 320 hp (239kW) @ 1,800 rpm |
Maximum Line Pull | 22,380 lbs 10,154.4 kg |
Maximum Line Speed No Load | 537 fpm 163.7 mpm |
Standard Upper Weights | 57,000 lbs 25,854 kg |
Standard Lower Weights | 25,000 lbs 11,339 kg |
Main Transport Load | 93,600 lbs 42,456 kg |
Overflow Loads | 3-4 3-4 |
Key Features
- NEW Fly pinning designed for limited ladder use and ELIMINATES hammering pins
- Lightweight nylon head sheaves reduce overall machine weight and increase lift capacities
- Quick reeve boom head with quick reeve block allows rope to be easily reeved over boom head
- Hammerhead boom nose allows operator to work at high boom angles
- Greaseless wear pads
- Optional auxiliary sheave off main boom
- Pick-and-carry the whole chart
- List chart selections in LMI
- Transports complete in FOUR or FIVE LOADS
- Main unit transports 93,600 lbs (42 456 kg) with sideframes removed
- Three to four overflow loads under 44,500 lbs (20 185 kg)
- Four wide-spread hydraulic jacks for easy sideframe assembly/disassembly
- 2 mph (3.2 kph) high speed travel
- Fold-up catwalks
