TCC-1200
Base Rating | 120 USt @ 10 ft 110 Mt @ 3 m |
---|---|
Main Boom | Five Section Formed Boom Five Section Formed Boom |
Length (min-max) | 40 - 150 ft 12.2 - 45.7 m |
Telescope System | Full Power Full Power |
Attachment - Option 3 | 10 - 31 - 55 ft Stowable, 3-Piece bi-fold lattice fly 3.0 - 9.4 - 16.7 m Stowable, 3-Piece bi-fold lattice fly |
Maximum Tip Height | 211 ft 64.3 m |
Engine Make & Model | Cummins QSL 9L Cummins QSL 9L |
Horsepower | 320 (239kW) 1,800 rpm 320 (239kW) 1,800 rpm |
Maximum Line Pull | 21,120 lbs 9,579.9 m |
Maximum Line Speed No Load | 537 fpm 163.7 mpm |
Standard Upper Weights | 51,000 lbs 23,133.2 kg |
Standard Lower Weights | 25,000 lbs 11,339.81 kg |
Main Transport Load | 89,000 lbs 40,369.7 kg |
Overflow Loads | 3 3 |
Key Features
- Variable displacement piston type main pumps with total horsepower control
- Main hoists powered through piston motors and winch planetary drums grooved for 7/8” (22mm) wire rope
- Three working gauges
- Multiple counterweight configurations
- Optional three-piece bi-fold fly with integral 10’ (3.08 m) tip extension, perfect for two load line picks
- Lightweight nylon head sheaves reduce overall machine weight and increase lift capacities
- Quick reeve boom head with quick reeve block allows rope to be easily reeved over boom head
- Hammerhead boom nose allows operator to work at high boom angles
- Greaseless wear pads
- Optional auxiliary sheave off main boom
- Pick-and-carry the whole chart
- List chart selections in LMI
- New state-of-the-art load moment indicator
- 40% gradeability
- Transports complete in THREE or FOUR LOADS
- Main unit transports under 89,000 lbs (40 370 kg) with side frames removed
- Three overflow loads under 44,500 lbs (20 185 kg)
- Four wide-spread hydraulic jacks for easy side frame assembly/disassembly
- 2 mph (3.2 kph) high speed travel
- Fold-up catwalks
